Два цвета Экструзионная линия для производства коктейльных соломинок
корзина запросов
OEM：
Available
Sample：
Available
Port：
Ningbo
Payment：
PayPal,VISA,MasterCard,Western Union,L/C,T/T
Place of Origin：
China
Shipping：
Sea freight · Land freight · Air freight
Supply Ability：
300 unit per Year
Подробная информация о продукции
Два цвета Экструзионная линия для производства коктейльных соломинок
DESCRIPTION
This model is a tube extrusion line, composed of extruder and die ,Vacuum calibration and cooling unit,haul-off unit, rotary cutter unit,
The series machines can produce all kinds of drinking straw,spiral strip straw,medical pipe, all the machine’s controls base with the control elements ergonomically adapted to permit easy operation.
TECHNICAL FEATURE
1.The extrusion die can be special designed and easy exchanged to produce pipe and shaping stuff,
2.Water bath in stainless steel can be adjusted in three planes ,
3.The haul-off unit can be belt or rollers, it is customizable.
4.Fitted with single or double rotary cutter .
SPECIFICATIONS
|
Model
|
KD-11
|
KD-12
|
KD-13
|
|
|
Parameter of main screw
|
φ50mm(diameter)
|
|||
|
Parameter of sub- screw
|
0
|
1×φ25mm
|
2×φ25mm
|
|
|
Capability
|
25~35Kg/h
|
|||
|
Power
supply
|
Main motor
|
11kW 380v 50Hz (VFD)
|
||
|
Sub motor
|
0
|
0.75kW×1
|
0.75kW×2
|
|
|
Haul-off motor
|
0.75kW×1(VFD)
|
|||
|
Cutting motor
|
0.75kW×1(VFD)
|
|||
|
Temperature controller
|
5zone
|
8 zone
|
11 zone
|
|
|
Length of cooling container
|
2400mm/3400mm/4400mm
|
|||
|
Specifications
|
diameter:φ2~14mm thickness:0.05~1mm
|
|||
Other specifications are customizable
